Micro Inverter Manufacturers & Suppliers in China
As a leading manufacturer of Micro Inverters, we are committed to providing highly efficient and stable solar inverter solutions to our customers around the world. Our Micro Inverter uses advanced technology to optimize each solar panel independently, significantly improving the overall efficiency and reliability of the system. Whether it’s a rooftop home, a commercial building, or a large-scale PV plant, our products excel in a variety of application scenarios.
Micro Inverter Manufacturers & Suppliers in China
Feature:
Input Voltage: 60V
Output Voltage: 230V / 0.85Un-1.1Un
Output Current: 2.6A
Output Frequency: 50/60 HZ
Output Type: Single
Size: 21223040mm
Type: DC/AC Inverters
Inverter Efficiency: 96.5%
Certificate: IEC/ UL
Warranty: 5 Years
Weight: 3.5kg
Color: White
7KW
2KW
1KW
| Model | SUN300G3-US-220 | SUN300G3-EU-230 | SUN500G3-US-220 | SUN500G3-EU-230 |
| Input Data (DC) | ||||
| Recommended input Power (STC) | 210~420W (1 Piece) | 210~420W (1 Piece) | 210~600W (1 Piece) | 210~600W (1 Piece) |
| Maximum input DC Voltage | 60V | |||
| MPPT Voltage Range | 25~55V | |||
| Full Load DC Voltage Range (V) | 30~55V | 30~55V | 40~55V | 40~55V |
| Max. DC Short Circuit Current | 19.5A | |||
| Max. input Current | 13A | |||
| No.of MPP Trackers | 1 | |||
| No.of Strings per MPP Tracker | 1 | |||
| Output Data (AC) | ||||
| Max. Output Apparent Power (VA) | 300 | 300 | 500 | 500 |
| Rated Output Power (W) | 300 | 300 | 500 | 500 |
| Rated Output Current (A) | 1.4 | 1.3 | 2.3 | 2.2 |
| Nominal Voltage / Range(this may vary with grid standards) | 220V/0.85Un-1.1Un | 230V/0.85Un-1.1Un | 220V/0.85Un-1.1Un | 230V/0.85Un-1.1Un |
| Nominal Frequency / Range | 50 / 60Hz | |||
| Extended Frequency/Range | 45~55Hz / 55~65Hz | |||
| Power Factor | >0.99 | |||
| Maximum units per branch | 17 | 17 | 10 | 10 |
| CEC Weighted Efficiency | 95% | |||
| Peak Inverter Efficiency | 96.5% | |||
| Static MPPT Efficiency | 99% | |||
| Night Time Power Consumption | 50mW | |||
| Mechanical Data | ||||
| Ambient Temperature Range | -40-60℃, >45℃ derating | |||
| Size (mm) | 189×184×31.5 (Excluding Connectors and Brackets) | |||
| Weight (kg) | 2.15 | |||
| Cooling | Free Cooling | |||
| Enclosure Environmental Rating | IP67 | |||
| Communication | WIFI | |||
| Grid Connection Standard | VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1,G98, G99, C10-11, UNE217002, NBR16149/NBR16150 | |||
| Safety EMC / Standard | UL 1741, IEC62109-1/-2, IEC61000-6-1, IEC61000-6-3, IEC61000-3-2, IEC61000-3-3 | |||
| Warranty | 10 years | |||
Custom Micro Inverter For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples of Micro Inverter that you can take advantage of.
Get Micro Inverter From Solarinvertermanufacturer.com Step By Step
Meet different needs
As a leading Micro Inverter manufacturer in China, we have a wide range of products that can provide a variety of power ranges and adaptable solutions to meet the diverse needs of different customers.
Product customization and quality assurance
Our products are not only powerful, but also have global certifications (e.g., CE, UL, etc.), and as a local manufacturer in China, we have complete quality control during the production process to ensure that every device received by our customers is flawless.
Flexible Pricing and Payment Methods
As a China Micro Inverter manufacturer, we are able to provide customers with more cost-effective products through our efficient production process and low-cost manufacturing advantages, while flexible payment terms and good after-sales protection ensure your purchasing experience smooth.
Fast delivery and excellent after-sales service
Benefit from your committed Micro Inverter Manufacturers & Suppliers
Accept small orders, test orders
No matter how big your order is, we will take it seriously. Ensure that every transaction is completed perfectly and live up to your expectations of us.
Strong ODM and OEM capabilities
We have a strong design and R&D team with rich experience in OEM and ODM, applying for more than 20 innovative designs every year, you give us the order, we give you the peace of mind.
Strong Supply Chain
We have a strong supply chain, even if you do not need our brand, we can provide you with a variety of brands of products at affordable prices.
Custom Micro Inverter For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples of Micro Inverter that you can take advantage of.
What Other Inverter or Power Products You Want
You don’t need to have any experience in importing Micro Inverter wholesale from China, because a professional portable power bank supplier will guide you step by step until you receive it in your country, We have exported Micro Inverter to the USA, Canada, New Zealand, Australia, Singapore, UK, and EU. But how to verify good quality when you buy 7.2kw on portable solar generator wholesale from China, Contact us for more details.
Custom Micro Inverter For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples of Micro Inverter that you can take advantage of.
