Residential Three-Phase Photovoltaic + BESS System Solar Energy Storage Off-Grid System 10kW Lithium Battery Integrated Cabinet Manufacturer and Supplier in China
- Model: XT-LB8000P3/XT-LB10000P3/XT-LB12000P3
- Three-phase residential ESS 8 kW/10 kW/12 kW
- MPP voltage range/rated input voltage: 180 V to 850 V
- Battery voltage: 125 V to 600 Vdc
- Nominal AC voltage: 400 Vac/360 V to 440 Vac
- Battery type: Lithium-ion battery
- Battery capacity: Up to 30 kWh
Choose our cabinet system to provide stable and efficient power storage for your power system and reduce your power costs while enjoying green energy.
Commercial and Industrial Energy Storage Systems Chinese Manufacturer
commercial-and-industrial-energy-storage-system-outdoor-cabinet-215kWh-lithium-iron-phosphate-integrated-cabinet
Residential Energy Storage System Solar Power Generation Home Complete Photovoltaic Panel Hybrid Off-Grid and Grid-Connected Machine Lithium Battery Integrated Cabinet
10ft container DC-coupled ESS solar energy storage off-grid system lithium battery integrated cabinet complete set
Outdoor Cabinet AC Coupled ESS Solar Energy Storage Off-Grid System
40ft container DC-coupled PV+ESS
20ft container AC coupled PV+ESS
| Parameter | XT-LB6000P3 | XT-LB8000P3 | XT-LB10000P3 | XT-LB12000P3 |
|---|---|---|---|---|
| PV Input | ||||
| Max PV Input Power | 7.8kW | 10.4kW | 13kW | 15.6kW |
| Max PV Input Voltage | 1000V | |||
| MPPT Voltage Range | 125V-850V | |||
| Max PV Input Current | 12.5A*2 | |||
| MPPT Trackers / Strings per MPPT | 2/1 | 2/1 | 2/1 | 2/1 |
| AC Output | ||||
| Grid Type | 3W+N+PE | |||
| Rated Output Power | 6.6kVA | 8.8kVA | 11kVA | 13.2kVA |
| Rated Output Current | 9.5A | 12.7A | 15.9A | 19.1A |
| Rated Output Voltage | 400VAC / 360Vac-440Vac | |||
| Rated Output Frequency | 50/60Hz | |||
| Power Factor | 0.99lagging-0.99leading | |||
| THDi | <3% | |||
| EPS Output | ||||
| Rated Output Power | 6.6kVA | 8.8kVA | 11kVA | 13.2kVA |
| Rated Output Current | 9.5A | 12.7A | 15.9A | 19.1A |
| Rated Output Voltage | 400Vac | |||
| Rated Output Frequency | 50/60Hz | |||
| Switch Time | <20ms | |||
| THDu | <2% | |||
| Battery Parameters | ||||
| Battery Voltage | Customizable | |||
| Battery Type | Lithium Iron Phosphate | |||
| Battery Capacity | up to 30kWH | |||
| Max Parallel | 6 | |||
| Cycle Life | >10years (25°C /77F) | |||
| Max Charge/Discharge Current | 50A | 50A | 50A | 50A |
| System Parameters | ||||
| Protection Grade | IP20 | |||
| MPPT Efficiency | 99.9% | |||
| Max Efficiency | 97% | |||
| Inverter Topology | Without transformer | |||
| Self Consumption | <3W | |||
| Interface: Rs485/wifi/lan /can/drm | yes/opt/opt/yes/yes | |||
| Display | LCD | |||
| Operating Temperature | -10°C~60°C | |||
| Relative Humidity | 15%~85% (non-condensing) | |||
| Altitude | 2000m | |||
| Dimension (W/H/D) mm | 600*600*1610mm/600*600*1833mm | |||
| Weight | / | |||
| Safety Standard | IEC 62109-1&2,IEC 62477,CE-EMC | |||
Custom Energy Storage System For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples of Solar Battery that you can take advantage of.
Get Residential Three-Phase Photovoltaic + BESS System Solar Energy Storage Off-Grid System 10kW Lithium Battery Integrated Cabinet Wholesale Step By Step
We Respond To Your Inquiry Within 12-24 Hours
By choosing our Energy Cabinet, you are not just buying a device, you are guaranteeing your energy independence and quality of life. Our inverters utilize high-efficiency, long-life core components, and through strict quality control, ensure stable operation regardless of high temperatures, humidity, or extreme environments, giving you a 24-hour uninterrupted power supply. Whether you are in a remote mountainous area or an island resort, you can enjoy reliable power support and live with peace of mind.
We Offer Various Customized Services
We know that the convenience brought by technology is the power to change life. Our Energy Cabinet are equipped with an intelligent control system, which allows you to monitor the battery status, power generation and load in real time through the cell phone app, so that you can know the system operation status anytime and anywhere. No more complicated operation and maintenance, one-button operation makes power management easier and more intuitive than ever, helping you save time and energy.
We Fulfill Efficient And Automated Manufacturing
In today’s global advocacy of environmental protection, by choosing our Cabinet, you are not only creating more convenience for your own life, but also contributing to the sustainable development of the planet. Our inverters support a wide range of renewable energy inputs and work with solar, wind and other green energy sources to effectively reduce your carbon footprint and power consumption. Eco-friendly and money-saving, bringing you double rewards, step towards a green life, start from here.
Power Packaging & Transportation
Benefit from your Residential Three-Phase Photovoltaic + BESS System Solar Energy Storage Off-Grid System 10kW Lithium Battery Integrated Cabinet Manufacturer and Supplier in China
Accept small orders, test orders
No matter how big your order is, we will take it seriously. Ensure that every transaction is completed perfectly and live up to your expectations of us.
Strong ODM and OEM capabilities
We have a strong design and R&D team with rich experience in OEM and ODM, applying for more than 20 innovative designs every year, you give us the order, we give you the peace of mind.
Strong Supply Chain
We have a strong supply chain, even if you do not need our brand, we can provide you with a variety of brands of products at affordable prices.
Custom Energy Cabinet For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples for your solar system and reduce your power costs while enjoying green energy. that you can take advantage of.
What Other Inverter or Power Products You Want
You don’t need to have any experience in importing Energy Cabinet wholesale from China, because a professional Energy Cabinet supplier will guide you step by step until you receive it in your country, We have exported Energy Cabinet System to the USA, Canada, New Zealand, Australia, Singapore, UK, and EU. But how to verify good quality when you buy best Energy Storage System Bulk from China, Contact us for more details.
Custom Cabinet For Your Brand
We provide custom solutions to all our customers and offer free consulting or samples of Solar batteries that you can take advantage of.
